MEGATRON is launching two new S-beam pressure sensors with built-in analogue amplifiers: The KT1405 and KT1505 measure switching and actuation forces between 50 N and 10 kN with the best accuracy by way of a full-bridge pressure gauge circuit.
The KT1405 S-Beam pressure sensor is right for purposes involving small to medium pressure ranges, from 50 N to 1 kN. The KT1505, alternatively, measures forces between 1 kN and 10 kN. Each sensors can measure compressive or tensile forces, and bidirectional compressive and tensile forces could be measured utilizing only a single sensor if required. That is made doable by the built-in analogue electronics, which offer a bipolar voltage output starting from −10 V to +10 V, along with the 0–10 V and 4–20 mA output sign choices. The pressure transducer offers info on the path of the pressure by way of this output: compressive forces generate a constructive sign (0 to +10 V) and tensile forces generate a adverse sign (0 to −10 V).
Compact dimension with diminished cabling necessities
The brand new S-Beam pressure sensors boast a powerful response time of beneath 1 ms and a cut-off frequency of 1,600 Hz. As they function an analogue amplifier, there isn’t a want for cumbersome exterior electronics. Regardless of their built-in electronics, the sensors are extremely compact, measuring 70 mm x 64 mm x 34 mm (KT1405) and 80 mm x 71 mm x 40.5 mm (KT1505), respectively. Moreover, their cabling necessities are considerably decrease than these of sensors with a separate amplifier. All pressure sensors are calibrated and examined on the manufacturing facility, and a check report documenting compliance with the desired measurement values for the chosen nominal pressure is provided.
The KT1405 sequence of S-Beam pressure sensors is often utilized in meeting, dealing with, dosing, packaging and testing programs. KT1505 sequence sensors are perfect for measuring pressure in manufacturing crops and gear, in addition to in dosing and packaging programs. They may also be used to watch becoming a member of and meeting processes.
